Wave Guide Gaskets

Conductive Wave Guide gaskets are highly electrically conductive, mechanically resilient and conformable vulcanized gaskets which provide low interface resistance between mating electronic enclosure flanges or covers while simultaneously providing moisture, pressure, or environmental sealing. The maximum pressure is limited to 20 psi.

Available in the following materials:

  • - Silver Coated Copper Filled HD Silicone (ECR-110)
  • - Silver Coated Aluminum Filled HD Silicone (ECR-214)
  • - Silver Coated Copper Filled Silicone with copper mesh (ECR-107)
