Silver Coated Aluminum Filled Silicone  (ECR-102)                                                   Proudly MADE IN USA



Available as below:

* Tubing                                                                                      All Products are manufactured in Anaheim, CA . USA

* Cords

*  Solid D-Profiles

* Hollow D-Profiles                                                                  CALL US: 1-888-327-7122 / 714-414-0977

* Solid P-Profiles                                                                      Email: emigaskets@gmail.com

* Hollow P-Profiles                                                                  http://www.emiconductiverubberllc.com

* Wave Guide Gaskets                                                                         FAX: 714-414-1179

* Die-cut Gaskets

* Molded Gaskets

* Extruded Gaskets

* Molded Sheets

* Molded O-Rings

* Molded D-Rings

* Molded P-Rings

* Custom Extruded Shapes (profiles)

* Custom Molded Parts


Product Description:


This material is specifically engineered for EMI/RFI applications where it will subject to Galvanic Corrosion Environment.  It is light and very common being used in Aerospace and Military Applications and high end Electronic, satellite products.  It is very compatible and strongly preferred when using with aluminum mating parts. This material will withstand temperature from -55°C to 160°C. Excellent in Electrical Conductivity. Excellent in Galvanic Corrosion Resistance.  The characteristics are included as follow:


- EMI/RFI Shielding

- Hot/Cold Temperatures

- Galvanic Corrosion Resistance

- Ozone Resistance

- Low Outgassing Resistance

- Temperature Stability between -55°C to 160°C

- Military/Aerospace/Electronic Applications


Applications:

Military/Aerospace/Electronic Applications


Specifications:

- Specific Gravity (g/cc): 1.90 ± .25

- Hardness (Shore A): 65 ± 7

-Tensile (psi): 200 Min

-Elongation (%): 100 Min / 300 Max

- Tear Strength (ppi): 30 Min

- Volume Resistivity (ohm-cm): 0.008
